High liquid level horn BME-100 BAUMAN

tab22_img01

tab22_img02

Secifications Flow Dimension Weight In/Out Compressor Element No
Model Nm3/min H x L x H1(mm) Vessel Element mm HP (xQuantity)
BME20 2.6 1,065 x 490 x 738 190 9 25F 20 EBME-20
BME50 6.5 1,164 x 490 x 840 199 9 40F 50 EBME-50
BME100 13 1,480 x 490 x 1,145 232 15 50F 100 EBME-100
BME150 19.5 1,767 x 490 x 1,500 238 23 65F 150 EBME-150
BME200 26 2,064 x 560 x 1,656 322 27 80F 200 EBME-200
BME300 39 2,011 x 620 x 1,656 371 32 100F 300 EBME-300
BME400 52 1,940 x 1,290 x 1,690 708 54 100F 400 EBME-200×2
BME600 78 1,940 x 1,290 x 1,690 816 64 125F 600 EBME-300×2
BME800 104 1,965 x 1,450 x 1,690 1,036 82 125F 800 EBME-400×2
BME1000 130 Contact Factory 1,166 108 150F 1,000 EBME-500×2
BME1200 156 Contact Factory 1,295 136 150F 1,200 EBME-600×2
BME1600 260 Contact Factory 1,832 214 200F 2,000 EBME-1,000×2
