로터리 중량 공급기
고정밀 정량 공급
Feeder application
- Cement plantsIn the cement industry, these systems are used for continuous feeding and dosing of clinker and process additives, as well as for precise measurement and control of cement loading and unloading during transport and bulk handling operations
- Metallurgy and Mineral Processing IndustryDosing of alumina, aluminum slag, iron ore concentrate, fluxes, and mineral dust
- Pulverized coalContinuous and accurate feeding of pulverized coal, fly ash, and ground biomass directly into the burners of thermal power plants and industrial boilers
- Variety of materials and sizesCement, gympsum, fillers, calcinated coke, dust, mortar production, powder, sand, small stones up to 20mm
- High StabilityThe double-deck rotor provides an excellent material and air-locking effect. This allows for the physical accumulation and sealing of powder materials, ensuring more stable feeding and preventing material flushing and flow interruptions
- High AccuracyEach rotor deck participates in material locking, feeding, and measurement, enabling 360-degree interval measurement and achieving an accuracy of up to ±0.5%
- Small installation spaceThe inlet and outlet are vertically aligned with a compact clearance of just 650 mm, making the unit suitable for most on-site plant layouts
- High temperature resistanceDesigned for both wear and temperature resistance. The scale body can withstand temperatures up to 250°C and features an internal anti-wear treatment, significantly reducing abrasion
Weighing Range: 5 ~ 300m3/h
Double-deck Rotor weigh Feeder
The double-deck rotor feeder is composed of a measuring feeder body, double-deck rotors, a feeder frame, a support device, speed and load cell measuring devices, and a control system.
Building upon mature rotor feeder technology and adapted to the characteristics of powdery materials, the rotor structure has been innovatively improved through a double-deck design. This configuration achieves physical accumulation and sealing of the powder, completely locking in the pulverized material and air. Consequently, it solves the material flushing problem often encountered when using a single-layer rotor to measure powder.
Building upon mature rotor feeder technology and adapted to the characteristics of powdery materials, the rotor structure has been innovatively improved through a double-deck design. This configuration achieves physical accumulation and sealing of the powder, completely locking in the pulverized material and air. Consequently, it solves the material flushing problem often encountered when using a single-layer rotor to measure powder.
Weighing Range: 5 ~ 600m3/h
Granular material Rotor weigh Feeder
Granular material rotor feeder has simple metering principle, compact structure, can withstand high temperature, low rate and easy maintenance. The scale (rotor) body is fully sealed and will not cause environmental protection problems. There is no need install special valves and the discharging speed can be controlled by it's own rotating speed.
Applications: Designed for metering bulk clinker and aggregates, as well as feeding various other granular materials.
Applications: Designed for metering bulk clinker and aggregates, as well as feeding various other granular materials.
Weighing Range: 30 ~ 850m3/h
Coriolis Mass Flow meter
The Coriolis weigh feeder for raw meal dosing includes a Coriolis mass flow meter and a control system. It significantly enhances the stability of kiln operating conditions, increases operational uptime and clinker strength, reduces energy consumption, and extends the service life of refractory materials. The feeder enhances the stability of kiln operating conditions.
- 4000 +Units installed
- 30Years of Experience
- 20+Countries we Serve
